ODM - Air Belt Conveyors HoverBELT® LGF
Energy-efficient, continuous and reliable conveying of bulk materials with the DI MATTEO Air Belt Conveyor
Application
Air Belt Conveyor uses an air cushion beneath the conveyor belt to reduce friction and lower energy consumption. It is particularly suitable for gentle and economical transport of bulk materials over short to long distances.
Efficient, low-wear bulk material conveying
DI MATTEO Air Belt Conveyors HoverBELT® enable economical bulk material transport over short and long conveying distances. Unlike conventional belt conveyors, the belt is not supported by idlers but glides on an air cushion generated by a compact fan unit. This significantly reduces the number of moving components, resulting in markedly lower wear and maintenance requirements.
Optimised belt guidance and extended service life
Low-friction belt guidance reduces belt tension and mechanical loads, contributing to extended belt service life. At the same time, stable and smooth belt tracking is ensured, minimising material backflow and supporting uniform conveying operation.
Low-maintenance, enclosed conveying system
The Air Belt Conveyor is designed as an enclosed, dust-tight system. This reduces dust emissions and protects the conveyed material from external influences. An optional self-supporting design eliminates the need for additional idlers and walkways. Various trough designs allow adaptation to different operating conditions.
Benefits
- Continuous, uniform material flow
- Reduced friction due to air-supported belt guidance
- Belt return configurations available with air support or roller support
- Enclosed design for low-dust conveying
- No additional idlers or walkways required
- Compact, space-saving design
- Low maintenance requirements, low operating costs and energy-efficient operation
ATEX compliant
For applications in hazardous areas, our equipment is available in compliance with ATEX Directive 2014/34/EU, ensuring safe and reliable operation in explosion-risk environments.
Modular
System Design
The modular system provides maximum flexibility: proven components can be combined, expanded or adapted as required. The result is an economical solution that grows with your requirements.
Customised
machine configuration
Each system is tailored to the specific conditions of your material and process. From component configuration to material selection, we deliver application-specific engineering that combines efficiency with reliable, long-term operation.
/ Available worldwide
Your personal contact
Do you have questions about our systems or are you planning a project? Contact our sales team for technical advice, detailed information and clear, engineered solutions. Globally connected, personally accessible – wherever you need us.
